1)
|
钕掺杂浓度:
|
浓度的10%以内0.1〜3 atm%的公差
|
2)
|
宽x高:
|
1*1~ 16*16mm
|
3)
|
长度:
|
0.02 ~ 20mm
|
1)
|
方向:
|
a-cut crystalline direction( /-0.20)
|
2)
|
尺寸公差:
|
/-0.1mm(typical)high precision /-0.005mm can be available upon request.
|
3)
|
波前失真:
|
|
4)
|
表面质量:
|
better than 20/10 scratch/dig per mil-o-1380a
|
5)
|
并行性:
|
< 10 arc seconds
|
6)
|
垂直度:
|
< 5 arc minutes
|
7)
|
表面平整度:
|
|
8)
|
通光孔径:
|
central 95%
|
9)
|
倒角:
|
0.15x450
|
10)
|
损坏阈值:
|
over 15j/cm2 (rods without coating) over 700 mw/cm2 (coating)
|
11)
|
coating:
|
(1) ar@1064nm, r< 0.1% (see coating 6-1) (2) ar@1064nm, r< 0.1% & ht@808nm, t>95% (see coating 6-2) (3) hr@1064nm, r>99.8% & ht@808nm, t>95%(see coating 6-3) (4) hr@1064nm, r>99.8%, hr@532 nm, r>99% & ht@808 nm, t>95%(see coating 6-4) (5) ar@1064 nm, r<0.1%, ar@532nm, r<0.3%(see coating 6-5) |
原子密度 | ~1.37x1020 atoms/cm2 |
晶体结构 | zircon tetragonal. space group d4h, a=b=7.12, c=6.29 |
密度 | 4.22 g/cm2 |
莫氏硬度 | glass-like, ~5 |
热膨胀系数 |
αa=4.43x10-6 /k, αc=11.37x10-6/k
|
导热系数 |
║c:5.23 w/m/k; ┴ c: 5.10w/m/k
|
part
|
size
(mm)
|
nd
|
coatings
|
|
s1
|
s2
|
|||
nyv001
|
3x3x1
|
0.5%
|
ar@1064nm, ht@808nm
|
ar@1064nm,
|
nyv002
|
3x3x1
|
1%
|
ar@1064nm, ht@808nm
|
ar@1064nm,
|
nyv003
|
3x3x1
|
1%
|
hr@1064nm, ht@808nm,
|
ar@1064nm,
|
nyv004
|
3x3x1
|
1%
|
hr@1064nm,ht@808nm,hr@532nm
|
ar@1064nm,
|
nyv005
|
3x3x3
|
0.5%
|
ar@1064nm, ht@808nm
|
ar@1064nm, ht@808nm
|
nyv006
|
3x3x3
|
0.5%
|
hr@1064nm, ht@808nm
|
ar@1064nm, ht@808nm
|
nyv007
|
3x3x5
|
0.5%
|
ar@1064nm, ht@808nm
|
ar@1064nm, ht@808nm
|
nyv008
|
3x3x8
|
0.5%
|
ar@1064nm, ht@808nm
|
ar@1064nm, ht@808nm
|
nyv009
|
3x3x12
|
0.5%
|
ar@1064nm, ht@808nm
|
ar@1064nm, ht@808nm
|
nyv010
|
3x3x3
|
1.0%
|
ar@1064nm, ht@808nm
|
ar@1064nm, ht@808nm
|
nyv011
|
3x3x3
|
1.0%
|
hr@1064nm, ht@808nm
|
ar@1064nm, ht@808nm
|
nyv101
|
3x3x0.5
|
3.0%
|
hr@1064nm, hr@532nm,ht@808nm
|
ar@1064nm&532 nm
|
nyv102
|
3x3x1
|
1.0%
|
hr@1064nm, hr@532nm,ht@808nm
|
ar@1064nm&532 nm
|
nyv103
|
3x3x1
|
2.0%
|
hr@1064nm, hr@532nm,ht@808nm
|
ar@1064nm&532 nm
|
nyv104
|
3x3x3
|
1.0%
|
hr@1064nm, hr@532nm,ht@808nm
|
ar@1064nm&532 nm
|
nyv105
|
3x3x5
|
0.5%
|
hr@1064nm, hr@532nm,ht@808nm
|
ar@1064nm&532 nm
|
nyv106
|
3x3x2
|
1.0%
|
hr@1064nm, hr@532nm,ht@808nm
|
ar@1064nm&532 nm
|
nyv107
|
3x3x2
|
0.5%
|
hr@1064nm, hr@532nm,ht@808nm
|
ar@1064nm&532 nm
|
